Description
Velocity Series Powered Trailer Jack, Side Mount, 12,000 lbs. Support Capacity, Bolt-On, 24 Inch Travel
Description
BULLDOG Velocity Series High Speed Jack is designed to be fast, powerful, and easy to install. Our proprietary high-speed system offers up to 12,000 lbs. of fully powered lift capacity per leg
- Fits a variety of applications for OEM and Aftermarket Industrial, Horse & Livestock, and RV Applications
- Easy to install Mounts without welding and requires no hydraulic oil, hoses, or pumps
- Fully Powered 12,000 lbs. capacity per leg with Proprietary high-speed system
- 24 of travel
- Approximate Travel Speed and Current Draw:
- 31 Inches per minute at no load, 15 amps
- 30 Inches per minute at 4,000 lbs., 40 amps
- 26 Inches per minute at 8,000 lbs., 65 amps
- 21 Inches per minute at 12,000 lbs., 100 amps
Specifications
| BRAND: | BULLDOG |
| PART NUMBER: | 185400 |
| WARRANTY: | LIMITED 5 YEAR WARRANTY |
| WEIGHT: | 102 LBS |
| CAPACITY: | 12,000 LBS. |
| TRAVEL: | 24 IN. |
| HARDWARE INCLUDED: | NO |
| RETRACTED: | 27.375 IN. |
| SPEEDY LIFT: | NO |
| EXTENDED: | 39.875 IN. |
| COLOR: | BLACK |
| ATTACHED WHEELS: | NO |
| MATERIAL: | STEEL |
| FOOT WIDTH: | 9.7 IN. |
| FOOT LENGTH: | 10 IN. |
| CYLINDER DIAMETER: | 5 IN. SQ. |
