Description

Highlights:

• Includes one 50″ light bar
• Comes in 2000K amber color
• Uses a 80? W x 50? H & 20? W x 8? H combo beam pattern
• Trusted by rally & endurance race teams
• Great for off-road use

Off-Road Proven Combo Beam

Professional rally drivers need great lighting on the racetrack to zoom safely across the track and secure a victory. You too can win when you try a new aluminum PCB SS50 Stage Series 50″ Amber Combo LED Light Bar from Diode Dynamics. It is designed to function great, fit compactly, be durable, use combo beams, and to implement custom TIR optics. All of Diode Dynamics’s beam patterns were made with optical simulation modeling to make the best pattern possible. This specific model uses both a flood and driving pattern to brighten your path. The 80? W x 50? H pattern provides even light unlike generic floods, which have been known to operate like heavily diffused spot beams. The flood offers a true spread of light to brighten up the countryside at low speeds or when backing up. The 20? W x 8? H pattern excels in directing light downrange while you are driving quickly. They coexist by featuring a single flood lens in the bar’s middle, and two driving lenses on the outside of the light bar. It has a peak beam intensity of 245,000 candela, uses 6,400 lumens and shines 2,004 lux at ten meters. The light’s 2000K color produces a a deep yellow color, perfect to cut through bad weather conditions. These lights are a clear choice for off-road trips, and only off-road. When installed in accordance with your state’s guidelines, the bar size meets SAE J581 standards and isn’t street legal.

Better Designed Than Competing Brands

The Diode Dynamics SS50 Stage Series 50″ Amber Combo LED Light Bar was built to be a compact and focused choice. The housing doesn’t whistle in the wind like some other light bars do, because of its clever aluminum heatsink design. It also extrudes with a narrow-profile in order to fit in small areas. Because of its short 1.65″ height, it will fit in spots that more traditional dual-row light bars couldn’t fit. While it might be natural to assume smaller means weaker, that’s not the case with this light bar. High-intensity Lumileds LED chips paired with a total internal reflection (TIR) optic ensure much more light output than your typical optics or reflectors. Standard optics lose light internally, increase glare and do not focus light properly. The TIR optic receives all the LED’s light, directs it where needed, and reduces glare, all at an efficient rate. This light bar also features replaceable, individual lenses and a double-wall seal. Each 6″ segment features an outer polycarbonate lens that can be replaced if you desire a different kind of beam or color. The light will additionally thrive in all weather conditions and function in temperatures ranging from -40 to 185 degrees Fahrenheit.

Features Easy Connections

Stage Series LED lights utilize standard DT type Deutsch-style connector and a 6″ pigtail with bare leads. Light Specs:

• Watts: 259 W
• Amps @ 13.2 V: 18.5 A
• Peak Beam Intensity: 245,800 cd
• Lux @ 10 M: 2,004 lux
• Raw Lumens: 6,400 lm
• Light Color Temperature: 2000K

Kit Contents:

• One SS50 LED light bar
• One wire pigtail
• One universal mounting bracket
