Diode Dynamics SS6 Stage Series 6 inch White Driving LED Light Bar (Pair) | DD5014P

Diode Dynamics SS6 Stage Series 6 inch White Driving LED Light Bar (Pair) | DD5014P

Original price was: $299.95.Current price is: $89.99.

SKU: DD5014P Category: Tag:

Description

Highlights:

  • Includes two 6″ light bars
  • Comes in 6000K white color
  • Uses a 20-½ W x 8-½ H driving beam pattern
  • Trusted by rally & endurance race teams
  • Great for off-road but also legal for street use

Off-Road Proven/Street Legal Driving Beam

Professional rally drivers need great lighting on the racetrack to zoom safely across the track and secure a victory. You too can win when you try a new aluminum PCB SS6 Stage Series 6″ White Driving LED Light Bar from Diode Dynamics. It is designed to function great, fit compactly, be durable, use driving beams, and to implement custom TIR optics. All of Diode Dynamics’s beam patterns were made with optical simulation modeling to make the best pattern possible. This specific model uses a driving pattern to supplement your high beams. The 20-½ W x 8-½ H pattern excels in directing light downrange while you are driving quickly. It has a peak beam intensity of 55,000 candela, uses 1,400 lumens and shines 550 lux at ten meters. The light’s 6000K color, Diode Dynamics’s most possible color, produces a true white color without any hue of blue. While these lights are a clear choice for off-road trips, they also work superbly on the street. When installed as a pair and in accordance with your state’s guidelines, the driving pattern meets SAE J581 standards and keeps your vehicle street legal.

Better Designed Than Competing Brands

The Diode Dynamics SS6 Stage Series 6″ White Driving LED Light Bar was built to be a compact and focused choice. The housing doesn’t whistle in the wind like some other light bars do, because of its clever aluminum heatsink design. It also extrudes with a narrow-profile in order to fit in small areas. Because of its short 1.65″ height, it will fit in spots that more traditional dual-row light bars couldn’t fit. While it might be natural to assume smaller means weaker, that’s not the case with this light bar. High-intensity Lumileds LED chips paired with a total internal reflection (TIR) optic ensure much more light output than your typical optics or reflectors. Standard optics lose light internally, increase glare and do not focus light properly. The TIR optic receives all the LED’s light, directs it where needed, and reduces glare, all at an efficient rate. This light bar also features replaceable, individual lenses and a double-wall seal. Each 6″ segment features an outer polycarbonate lens that can be replaced if you desire a different kind of beam or color. The light will additionally thrive in all weather conditions and function in temperatures ranging from -40 to 185 degrees Fahrenheit.

Features Easy Connections

Stage Series LED lights utilize standard DT type Deutsch-style connector and a 6″ pigtail with bare leads. Light Specs:

  • Watts: 26.6 W
  • Amps @ 13.2 V: 1.9 A
  • Peak Beam Intensity: 55,000 cd
  • Lux @ 10 M: 550 lux
  • Raw Lumens: 1,400 lm
  • Light Color Temperature: 6000K

Kit Contents:

  • Two SS6 LED light bars
  • Two wire pigtails
  • Two Universal mounting brackets
