Description
2019-2023 Ram 2500 Diesel 4WD 4.5” Coil Spring Lift KitThe all-new 4.5″ Coil Spring Lift Kits allow for even more ground clearance while going to a 37″ tire. Springing up to the new 4.5″ lift yields all the bells and whistles of a big 6″ kit but at a slightly lower, garage-able stance. These kits come with heavy-duty steel radius arm drop brackets, heavy-duty fabricated steel front, and rear (2500 only) track bar brackets, forged dropped pitman arm, sway bar relocation brackets, and bump stop extensions preventing over-compression of the included Falcon 1.1 Monotube front & rear shocks. Both 4.5″ Ram HD kits include our unique CNC-machined 6061-T6 billet Aluminum Driveline Indexing System (DIS) that re-clocks the transfer case to properly align the front output shaft for improved driveline angles. The Ram 2500 HD comes with the standard output diesel engine DIS system. Kit 49-19420 includes everything in our popular 6 lift kit as well as these new DIS re-positioning components. Heavy duty and great riding 4.5″ lift front springs, 3″ lift rear coil spring spacers, heavy-duty radius arm drop brackets, heavy-duty fabricated steel front, and rear track bar brackets, dropped cast iron pitman arm, front/rear sway bar relocation brackets and bump stop extensions preventing over-compression of the new Falcon 1.1 Monotube shocks front/rear shocks are all included in this premium kit. For use on diesel 2500 trucks only.
- Allnew 20192023 Ram 2500 4WD HD 4.5″ lift kit
- Does not work with Factory Air suspension or Auto Level system (factory helper bags)
- Single Cab configuration has not been validated
- All Allnew 20192023 Ram 2500 4WD HD 4.5″” lift kit
- 4.54.5inch front/3inch rear spring lift kit
- Includes all Includes allnew transfer case clocking ring and new heavyduty transmission crossmember
- Allows for up to 37×13.50 tires on 20″” x 9″” wide wheels with Allows for up to 37×13.50 tires on 20″” x 9″” wide wheels with 18 offset
- 4.5inch front/3inch rear spring lift kit
- Includes allnew transfer case clocking ring and new heavyduty transmission crossmember
- Includes 4 Falcon 1.1 Monotube shocks tuned specifically for the Ram 2500 HD
- For use on Diesel engine Ram 2500 4WD HD trucks only
- Allows for up to 37×13.50 tires on 20″ x 9″ wide wheels with 18 offset
Application Summary:
| Year | Make/Model |
|---|---|
| 2019-2024 | Ram 2500 |
| Attributes | |
| Country of Origin (Primary) | US |
| Fitment | Direct Fitment, Direct Fitment |
| Front Lift Component | Coil Spring, Coil Spring |
| Front Lift Height | 4.5 Inches, 4.5 Inches |
| Front or Rear | Front and Rear, Front and Rear |
| Front Shocks | Falcon 1.1 Monotube, Falcon 1.1 Monotube |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Hazardous Material Code | N |
| Install Difficulty | Difficult Requires Professional Installation, Difficult Requires Professional Installation |
| Life Cycle Status Code | Available to Order |
| Lift/Drop Height | 4.5 in. |
| Max Tire Size | 37 Inch, 37 Inch |
| NAFTA Preference Criterion Code | B |
| Rear Lift Component | Coil Spring Spacer, Coil Spring Spacer |
| Rear Lift Height | 3 Inches, 3 Inches |
| Rear Shocks | Falcon 1.1 Monotube, Falcon 1.1 Monotube |
| SDR Required Flag | N |
| Shocks Included | Yes |
| GTIN | 00194933189656 |
