Description
Highlights:
- Classic Warn winch design with reliable operation
- 9,500lb maximum pulling power
- 6-horsepower series wound motor
- 3-stage planetary gear train
- 100ft steel cable
- Includes roller fairlead
- Backed by a limited lifetime warranty
Highly Reliable Winch with Impressive Pulling Power
Warn’s winches have been getting off-road vehicles out of tough jambs out there on the trail for decades, and the Warn 9.5XP 9,500lb winch has been one of the workhorses of Warn’s lineup for most of that time. The Warn 9.5XP winch provides reliable and and powerful pulling capability in practically any environment, climate, and application. Each 9.5XP Winch combines a powerful motor and specialized geartrain with a 100ft braided steel cable and a low-heat mechanical cone brake that work together to give the winch a smooth and fairly quiet operation while still providing a powerful pull in a reliable package that won’t let you or your off-road vehicle no matter what your adventure entails.
12V 6 Horsepower Motor, 3-Stage Gears, and 100-ft Steel Cable
The Warn 9.5XP is designed to fit on practically any rig or mount that you have in mind while still giving you reliable pulling power for all your off-road adventures. The Warn 9.5XP is built around a 12V, series wound 6 horsepower motor that’s capable of a 6.2 foot-per-minute line speed at its 9,500lb maximum load. The motor is paired with a 3-stage planetary geartrain with a 156:1 reduction ratio that provides smooth and fairly quiet operation. The 9.5XP’s mechanical cone braking system features impressive braking with low-levels of heat to help keep your winch cool in extreme situations. Each Warn 9.5XP winch has a compact design with removable control pack and a standard 10×4.5″ bolt pattern that makes it easy to mount to aftermarket mounting systems or bumpers. Each winch comes with a roller fairlead and comes backed by a limited lifetime warranty. Specifications:
- Rated Line Pull: 9,500lbs
- Geartrain: 3-stage planetary
- Gear Ratio: 156:1
- Clutch: Freespooling rotating ring gear
- Brake: Mechanical Cone
- Rope: Steel. 100ft x 5/16″ diameter
- Fairlead: roller fairlead
- Recommended Battery: 650 CCA Minimum
- Battery Leads: 72″
- Bolt Pattern: 10″ x 4.5″
